AIR! Readtail
The AIR! Readtail (Automatic Intelligent Reader) is probably the most versatile RFID product of the AIR! family catalog: easy to install on multiple surfaces, thought to face any industrial challenges you may imagine and suitable for a wide range of demanding industrial applications.
Specifically designed for severe environmental condition applications with demanding long distance and high speed read/write, such as vehicle identification, heavy logistics and high volume retail solutions. Inside, the single board core contains hardware modules, equivalents for HEART, BRAIN and MUSCLE.
Its powerful control board includes a battery unit meant to provide and keep enough energy to secure RFID data in case of an unexpected shut-down. It also runs the best in class current reading technology: an Impinj/Zebra reader, the “muscle” unit that sends and receives electromagnetic signal for the microPC to process. The “brain’s” proprietary software turns RFID inputs into business data, allows static filtering readings and permits fast integrations with any management system (SAP, ERP, CRM, DBMS).
WHAT

Designed

The AIR! Readtail is easy to install on multiple surfaces and reading different orientations (overhead, side, on base, lateral on wall, pole or ground for railway applications). AIR has a high gain internal antenna, with high circular pol arization and with three radiation pattern options: A11, A12 and A22.



kyubi system air! READTAIL

BENEFITS


  • Easy installation
  • Remote monitoring and maintenance
  • Flexibility of installation in different environments
  • Designed specifically for outdoor
  • Plug & Play
  • Compatible with EPCGlobal

APPLICATIONS


  • Rolling stocks control
  • Vehicles control (Trucks, vans, etc.)
  • Control of the income/outcome of an open-air storage depot
  • Control of the income/outcome of warehouses
  • Assets tracking
kyubi system air! READTAIL

TYPICAL APPLICATION

RFID SPECIFICATIONS

  • ETSI band - 865–868 Mhz
  • FCC Band - 902–928 Mhz
  • Supported TAGs - EPCglobal Class 1G2 ISO 1800-6C, ISO 1800-6B Ucode 1.19
  • Transmission power - +33 dBm / +36dBm
  • RFID Regulations - RoHS, ETSI EN 301 489, ETSI EN 302 208 y IEC 60950
  • Optional - Activation with external sensor

ENVIRONMENTAL SPECIFICATIONS

  • Operation temperature -20ºC to 50ºC
  • Relative humidity - 5% to 95% non condensing
  • Material - Policarbon, aluminum
  • Dimensions - 496 x 350 x 155 mm
  • Weight 12 Kg
  • Protection IP 65

POWER SUPPLY SPECIFICATIONS

  • Input voltage 100–240 Vac
  • Operating current 20W Maximum
  • Input frequency 50–60Hz
  • Output voltage 24VDC
  • Output current 3A maximum

AERIALS

  • The basic system is supplied with 1 internal antenna and two lateral antennas with the following characteristics:
  • ETSI band - 865–868 Mhz
  • FCC band - 902–928 Mhz
  • Input impedance - 50 Ohm
  • Internal antenna - Input connector female SMA
  • External antenna - Input connector female N

ASSEMBLY

  • Fixation - 4 subjection points, for the panoramic installation

COMMUNICATIONS

  • Local Ethernet (10/100 BaseT)
  • Visualization 1 status led (optional)
  • GPIO 2 movement sensors for the reading activation
PATRÓN DE RADIACIÓN KYU12

RADIATION PATTERN KYU12

  • Gain  -  9.5 dBi (902-928 MMz)
  • Beam width  -   70º / 40º
  • Axial Ratio @ broadside  -  <1.5dB
  • Axial ratio 3dB angular range   -   +/- 30º
  • Input impedance  -   50 Ohms
  • Polarization  -   LHCP
  • Connector  -  SMA Female
